Manufacturer: Boeing
|
|
Length: 231 ft, 10 in
|
|
Operating empty weight: 406,900 lb
|
|
Cruise altitude: 35,000 ft
|
|
Maximum range: 7,670 nm
|
|
|
|
Engines: 4 Pratt & Whitney PW4062
|
|
or 4 General Electric CF6-80C2B5F
|
|
Maximum payload: 148,100 lb
|
|
Passenger capacity: 416 3-class
|
|
or 524 2-class
|
|
|
|
|
747-400ER long range airliner
|
|
Wing span: 211 ft, 5 in
|
|
Max. landing weight: 652,000 lb
|
|
|
|
Cruise speed: Mach 0.855
|
|
|
|
Max. thrust: PW4062 - 63,300 lb (each eng.)
|
|
CF6-80C2B5F - 62,100 lb (each eng.)
|
|
|
|
Cargo: 5,599 cu ft (28 LD-1 containers + bulk)
|
|
|
|
|
|
|
|
|
Height: 63 ft, 8 in
|
|
Max. gross weight: 910,000 lb
|
|
Max. fuel capacity:
|
|
57,285 gal
|
|
63,705 gal with 2 body tanks
|
|
Max. weight FAR takeoff runway length:
|
|
10,900 ft at sea level
|
|
14,400 ft at 4,000 ft alt.
|
|
|
|
|
|
|
|
